Criticare nCompass 8100H Series Patient Monitor

(No reviews yet) Write a Review
SKU:
81H000XD
Condition:
New
$4,288.86

Description

Criticare nCompass 8100H Series Patient Monitor

Criticare’s nCompass 8100H Series Patient Monitor is the ideal option for busy environments that demand precise and reliable performance. With the ability to monitor adult and pediatric patients in essentially every department, the nCompass is exceptionally advanced.

This unit is easy to use with simplified menus and dedicated function keys. The nCompass mounts smoothly and quickly to walls and rollstands.

Includes a 2-year parts and labor warranty.

Standard Features:

  • ECG with Arrhythmia and ST Analysis, ComfortCuff NIBP, DOX SpO2, Heart Rate, Temperature, Respiration and Nurse Call interface connection
  • Mini-Trends display of condensed tabular vital signs data to display recent monitoring activity
  • Compatible with popular EMR systems for small and large offices
  • 12.1” touchscreen display interface
  • Interfaces with the Poet IQ 8500H agent gas analyzer for anesthesia monitoring

Optional Features:

  • End-tidal and inspired CO2, IBP and integrated printer
  • CO2 monitoring incorporates CSI’s patented water trap design with full occlusion clearing

Specifications:

ECG:

  • Number of Leads: 3-or 5 Lead
  • Lead View: User-selectable; I, II, III, aVR, aVL, aVF, V (5-Lead); II, II or III (3-Lead)
  • Gain Selection: x0.5, x1, x2, and x4
  • Frequency Response:
    • o   Diagnostic: 0.05 to 100  Hz (-3dB)
    • o   Monitor: 0.5 to 50 Hz (-3dB)
    • o   ST: 0.05 to 40 Hz (-3dB)
    • Electrosurgery Protection: Yes
    • Defibrillator Protection: Yes
    • Pacer Detection/Rejection: Yes
    • ST Accuracy: ±0.2 mm or ±5% of reading, whichever is greater, over heart range of 30 to 120 bpm
    • ST Range: -6.0 to 6.0 mm

NIBP:

  • Technique: Oscillometric upon in
  • Measurement Cycle: < 40 sec. typical
  • Auto. Measurement Cycles: 2, 3, 5, 10, 15, 30 min; 1, 2, 4 hr
  • Max. Allowable Cuff Pressure:
    • o   Adult/Pediatric: 300 mmHg
    • o   Neonate: 150 mmHg
    • Max. Allowable Cuff Range:
      • o   Adult/Pediatric: 30 to 300 mmHg
      • o   Neonate: 20 to 150 mmHg
      • Resolution: 1 mmHg
      • Transducer Accuracy: ±2 mmHg or ±2% of reading, whichever is greater, over full range
      • STAT Mode: 5 min of consecutive readings
      • Clinical Accuracy: Complies with AAMI
      • SP-10: 1st
      • 2002: 2nd

Pulse Oximetry:

  • Range: 1% to 99%
  • Resolution: 1%
  • Accuracy: 70% to 99% range: ±2%; 50% to 69% range: ±3%; < 50%: unspecified
  • Method: Dual wavelength LED

Heart Rate:

  • Source: User selectable – Smart, ECG, Pleth, NIBP, IBP
  • Range: 20 to 300 bpm (ECG, Pleth); 30 to 240 bpm (NIBP); 30-300 bpm (IBP)
  • Accuracy: ±1 bpm or ±1% (ECG) whichever is greater

Temperature:

  • Channels: 2
  • Probe: YSI-700 Series
  • Range, Accuracy: 68° to 113°F (20° to 45°C): ±0.1°C
  • Probe: YSI-400 Series
  • Range, Accuracy: 150 mmHg
  • Range: 59° to 113° F (15 to 45 C)
  • Display Resolution: ±0.1°


Capnography (CO2):

  • Units: mmHg, %; kPa; Torr
  • Method: Non-dispersive infrared; auto calibrating
  • N2O Compensation: Manual (On/O)
  • Range: 0 to 99 mmHg; 0 to 12.5%; 0 to 12.5 kPa; 0 to 99 Torr)
  • Resolution: 1 mmHg; 0.1%; 0.1 kPa; 1 Torr flow
    • o   Sample Rate: 200 ml/min
    • Accuracy: ±2 mmHg; ±0.3 vol. %; ±0.3 kPa; ±2 Torr or ±4% of reading, whichever is greater,  at 200 ml/min &  respiratory rate of ≤ 120 Br/min
    • Rise Time: 170 ms (10 to 90%) at 200 ml/min

IBP:

  • Channels: 1 or 3
  • Transducer Sites: Selectable: ART, PA, LV, RV, LA, RA, CVP, ICP
  • Pressure Range: -10 mmHg to 300 mmHg
  • Transducer Freq. Response: 0 to 20 Hz; Impedance >300 ohms; Transducer
  • Sensitivity: 5µV/V/mmHg
  • Accuracy: ±1 mmHg or ±1%, whichever is greater

Alarms:

  • Indication: Audible; Visual (EN 60601-1-8)
  • Silence: Yes; 2 minutes or permanent

Trends:

  • Memory: 24 hours at 30 second intervals
  • Display: Tabular, Graphical

Display:

  • Screen: 12.1” active color touch screen
  • Resolution:
    • o   Internal: 800 X 600 pixels
    • o   External: 800 X 600 pixels
    • Waveform: 6 maximum
    • Waveform Types: ECG leads I, II, III, aVR, aVL, V; CO2; Respiration; Pleth, IBP; breath-by-breath CO2; ST histograms; Mini-Trends; OXY-CRG
    • Sweep Speed: 6.25, 12.5, 25, or 50 mm/sec
    • Languages: English, Czech, French, German, Italian, Portuguese, Polish, Russian, Spanish, Turkish
    • Control Keys: 10; membrane-activated
    • Rotary Knob: Push and rotate; 2 steps/turn

System Outputs:

  • COM Ports: Two RS 232 compatible DB9 ports; USB (for software downloads only)
  • Nurse Call: Contact switch; 3.5 mm stereo phone jack, 14 mm
  • Defib/Sync: BNC connector
  • Video Port: Serial VGA compatible
  • DC Out: 5 VDC output for optional wireless accessory
  • External Module Port: 8-PIN circular connector

Printer (Optional):

  • Type: Internal thermal line
  • 12.5, 25 or 50 mm/sec

Physical Properties:

  • Weight: 12 lbs; 5.4 kg
  • Size: 12” (H) x 14.5” (W) x 11.5” (D)

Power Requirements:

  • Voltage: 100 to 240 VAC; 50/60 Hz
  • Power Consumption: 35 W, typical
  • Battery: 1 sealed lead acid
  • Power consumption: 35 W, typical
  • Battery Life: 2 hours, typical (3 hours, typical for base unit)
  • Power Consumption: 35 W, typical
  • Recharge Time: 4 to 6 hours, typical

Environmental:

  • Operating Temperature: 32° to 104°F (0° to 40°C)
  • Storage Temperature: 23° to 122°F (-5° to 50°C)
  • Operating Humidity: 15% to 90%, noncondensing
  • Operating Altitude: -300 to 3,000 meters

Classification:

  • Medical Device: Class II Equipment (IIb EU)
  • Electrical Protection: Class I Equipment
  • Degree of Protection: Type CF, Defibrillator-proof
View AllClose

Warranty Information

2-Year Parts and Labor Warranty
