Jaken Cardio-View PACS for Cardiology

Jaken Cardio-View DICOM Viewing, Reporting & Archiving Solutions: For Cardiologists looking for a high-quality Viewer at an affordable, low cost.

Jaken Cardio-PACS Features:

  • Viewers (local Cardio-PACS viewer and 3 Cardio-View SWRSVSCGN)
  • Upgrade with 5 Web-View Concurrent Licenses (UPPPCG-W05)
  • Window/Leveling
  • Pan
  • Zoom
  • CD - Import
  • CD - Burning on Cardio-PACS Station (option for Cardio-View SWRSVSCGB)
  • Windows print
  • Shutter
  • Magnifying glass
  • Pseudo color
  • Export image/series as DICOM, JPEG, BMP, AVI files
  • Study note creation
  • Attach documents to study
  • Attach non-dicom image to study (ie jpg)
  • Receive studies from PACS via DICOM
  • Query / Retrieve from PACS via DICOM
  • Send images and attached annotations / documents to PACS via DICOM
  • Rotate / Flip Orientation ICONS
  • Information Text overlay (patient name / study info)
  • Annotation graphics (line, curve, circle, text, arrow)
  • Basic Measurement (distance, Area, Angle, Cobb angle, Density, angle of intersecting lines, Heart / Chest Ratio)
  • EchoCardiology Measurement (Peak Pressure Gradient, Velocity Time Integration, LA volume Bi-Plane, Volume single plane, LV volume Modified Simpson's method Bi-Plane, Ejection Fraction, Deceleration Time, Diameter for Circular Area, Y0 Calibration)
  • Multi-Frame viewing and comparison with playback tools
  • Creates a Local "worklist" of all Studies and Patients for easy access and viewing
  • Can compare studies side by side on same monitor

 Macintosh & Portable Device Viewer (iPad, iPhone, Apple, Android Tablet & Phone):

  • Web based zero footprint viewers allowing access to patient images and medical reports through the browser.
  • Window/Leveling
  • Pan
  • Zoom
  • Rotate/Flip Orientation ICONS
  • Information Text Overlay (Patient name / study info)
  • Basic Measurement (Distance, Area, Angle)
  • Multi-Frame viewing and comparison with playback tools


  • To store, archive, view, distribute and manage DICOM images
  • Auto Send / Route Studies / Images
  • Manage DICOM Images with SQL DB
  • Secured Image Backup and Disaster Recovery with included external hard drive with data encryption
  • Licensed for 2 TB online storage management (additional storage capability available)
  • Licensed with DICOM Store Connection for Single Type Modality decided at time of purchase (additional modality available)
  • Included resident Cardio-View with echo cardiology tools on a server

 PACS Hardware Included:

  • Dell PowerEdge T620 Server
  • Dual Intel Xeon processors
  • 6 GB RAM
  • (3) 1TB Hard Drives RAID 5
  • 24" Dell Ultrasharp Color Flat Panel Display
  • 16X DVD+/-RW, Gigabit Network Interface Card
  • Windows Server 2008 x64 Standard, MS SQL Server Database
  • 2 TB External USB Hard Drive with signature preloaded for secured and encrypted image backup

 Minimum Recommended Specs for Cardio-View:

  • CPU - Intel Core 2 Processor
  • 4GB RAM
  • 74GB 10K RPM SATA Hard Drive
  • 48x CD-ROM
  • Video Display Driver Card
  • 10/100/1000 NIC
  • Video Monitor - 21" High-Resolution Flat Panel Display

 Possible Upgrades:

  • UPPPCG-W05 Upgrade to 5 Web-View Concurrent Licenses
  • UPPPCG-AS1T Storage License Upgrade - per extra 1 TB This upgrade also includes additional storage capacity on the encrypted external hard drive devices included in the package for secured image backup and disaster recovery
  • UPPPCG-MC Additional Modality Connection - per type
  • Addition of Cloud storage SWCLDAGT + subscription based on volume
  • Viewing, Reporting & Archiving Solution
  • High-quality viewer at an affordable price
  • 30 Day Trial Software
